Bringing Back Discontinued Damper Kits as Made-to-Order Kits!

CUCTOM MADE DAMPER
What is CUSTOM MADE DAMPER?
  • Adjustable damper kits discontinued in the past are now resurrected and available as made-to-order kits.
  • All the specifications, such as ride height drop and spring rate, are as same as the past ready-made items (except some vehicle models).
  • Available for sale from only 1 set.
  • Production leadtime is approximately 1.5 months after receiving an order.
  • Available through TEIN distributors / dealers worldwide.

If you would like to have the kit made to the different specifications (spring rates / damping force), it will be provided as "Specialized Damper"

Smell of Burning Compound Stirs the Soul…

SUPER DRIFT is made exclusively for drifting; developed for uncompromising people who would like to swing the car more freely, to enjoy real drifting to the extreme, and/or to lower the ride height.

We have renewed, revised and reset our Type HE damper to meet the demand of remarkably growing 'drift market'. We are now confidently releasing SUPER DRIFT, emphasizing more than ever on drift control.

Concepts

Sideway Setting
SUPER DRIFT was developed to specifically enhance drifting performance, and we have succeeded in bringing drifting controllability to the extreme.
It can fully exhibit its performance in grip driving, utilizing various features.
For Bigger Wheels & Bigger Tires
SUPER DRIFT is set up for the optimum performance with widely-used bigger tires / wheels, according to each vehicle models.

Specifications

A. Upper Mount
Pillow upper mount is set in each model for controlling the compliance, for realization of direct driving feel and handling incomparable with the original one.
B. Twin-Tube Structure
Twin-tube shell case is adopted for SUPER DRIFT in consideration of reliability, durability and cost effectiveness, enabling this high performance product to be offered to wide range of users at a reasonable price.
C. Full-Length Adjustment Function
Full-length adjustment system with movable lower bracket has been adopted, which enables the separate adjustment of the ride-height and pre-load.
D. Damping Force Adjustability
(Compression and Rebound Together)
SUPER DRIFT is equipped with ever-popular 16-level damping force adjustment function, for optimum performance on each different road conditions, such as city streets, winding roads and/or highways. Use of specially shaped needle valve enables linear damping force adjustment at each and every 16 levels.
E. Rust-Proofing
All threading parts are coated with specially formulated Fluorine, to prevent adherence and rust. Electroless nickel plating combined with clear painting is applied to lower brackets.
F. Complete Kit
Pillow upper mount is set in each model for controlling the compliance, for realization of direct driving feel. Shock absorbers, springs and pillow ball upper mounts come in 'complete kit' to assure correct settings (with springs at standard rates).
G. No-Sagging Spring
Straight spring made of high tensile steel, with tensile strength of 200kgf/mm2 (1960N/mm2), is used.
H. Conical Spring Washer
With existing full-length adjustable dampers, various vibration stresses might cause bracket lock to loosen in rare occasions. SUPER DRIFT has 'Conical Spring Washer' inserted between a bracket lock and a lower bracket, to effectively prevent loosening of a bracket lock even when drift-driving intensively.
SUPER DRIFT
